TECK90 INTERLOCKED ARMOUR CABLES

APPLICATION:
Teck90 is an armored interlocked electrical cable designed for many industrial applications. It is often used in petrochemical, pulp, and paper industries. It can be used as both open and concealed wiring. The wire is suitable for direct earth burial. Teck90 is used in ventilated, non-ventilated, and ladder-type cable trays. The wire is fit for service entrance above and below the ground. With HL glands, it is suitable for use in various hazardous locations. The electrical cable is rated at 90°C wet or dry. The voltage rating is 1000 volts. Teck90 can serve as a cheaper alternative to installations in conduit.

STANDARDS & REFERENCES：
• CSA C22.2 No. 131 & 174 - Type Teck 90 Cables
• ICEA S-95-658 - Power Cables Rated 2000 Volts or Less for the Distribution of Electrical Energy

CONSTRUCTION
Conductor: Bare copper Class B compact or compressed stranded
Insulation: Cross-Linked Polyethylene (XLPE) Type RW90
Ground (Bonding) Conductor: Uninsulated stranded bare copper conductor
Inner Jacket: Flame-retardant and moisture resistant Polyvinyl Chloride (PVC)
Armour: Aluminum Interlocked Armour (AIA)
Outer Jacket: Low-temperature, moisture and sunlight resistant Polyvinyl Chloride (PVC), black
Other coloured outer jacket and constructions available upon request

OPTIONS RANGE
Manufacturing range:
14 AWG to 1000 kcmil
Product Cores options:
- Single Conductor
- Two Conductor
- Three Conductor
- Four Conductor

High reliability

Super high pressure

Less maintenance

Technical Parameter

Single Conductor 1000V Two Conductor 1000V Three Conductor 1000V

XLPE/PVC/AIA/PVC

AWG Size		Insulation Thickness (in.)	Approximate Diameter (Over)				Net Weight w/Armour
Cond.	Bond Wire	Insulation Thickness (in.)	Insul (in.)	Inner Jacket (in.)	Armour (in.)	Outer Jacket (in.)	kg/km
4	6	0.060	0.350	0.490	0.730	0.810	610
3	6	0.060	0.380	0.520	0.760	0.840	680
2	6	0.060	0.420	0.560	0.780	0.870	760
1	4	0.080	0.490	0.660	0.880	0.960	1010
1/0	4	0.080	0.530	0.690	0.910	1.000	1130
2/0	4	0.080	0.580	0.710	0.950	1.040	1280
3/0	3	0.080	0.630	0.810	1.030	1.120	1610
4/0	3	0.080	0.690	0.860	1.080	1.170	1890
250	2	0.090	0.750	0.990	1.210	1.290	2210
300	2	0.090	0.770	1.040	1.280	1.370	2857
350	1	0.090	0.815	1.120	1.360	1.445	1910
400	1	0.090	0.850	1.155	1.395	1.480	3107
500	1/0	0.090	0.925	1.200	1.475	1.560	3740
600	1/0	0.090	1.005	1.305	1.545	1.655	4281
750	2/0	0.090	1.160	1.370	1.590	1.690	5230
1000	2/0	0.090	1.310	1.590	1.810	1.900	6590

XLPE/PVC/AIA/PVC

AWG Size		Insulation Thickness (in.)	Approximate Diameter (Over)				Net Weight w/Armour
Cond.	Bond Wire	Insulation Thickness (in.)	Insul (in.)	Inner Jacket (in.)	Armour (in.)	Outer Jacket (in.)	kg/km
14	14	0.045	0.170	0.470	0.670	0.760	388
12	14	0.045	0.180	0.510	0.720	0.800	445
10	12	0.045	0.210	0.590	0.790	0.880	557
8	10	0.045	0.240	0.630	0.860	0.940	723
6	8	0.060	0.310	0.780	1.030	1.130	1078
4	8	0.060	0.350	0.910	1.160	1.250	1444
3	6	0.060	0.380	0.970	1.220	1.300	1691
2	6	0.060	0.420	1.020	1.280	1.370	1951
1	6	0.080	0.490	1.210	1.440	1.540	2371
1/0	6	0.080	0.530	1.290	1.560	1.680	2837
2/0	6	0.080	0.580	1.380	1.650	1.770	3311
3/0	4	0.080	0.630	1.490	1.750	1870	3967
4/0	4	0.080	0.690	1.600	1.860	1.980	4772
250	4	0.090	0.750	1.800	2.050	2.170	5655
300	4	0.090	0.760	1.885	2.125	2.235	6637
350	3	0.090	0.860	2.010	2.260	2.400	7409
400	3	0.090	0.850	2.075	2.315	2.455	8511
500	3	0.090	0.990	2.270	2.520	2.660	9798
600	2	0.090	1.005	2.410	2.650	2.790	11828
750	2	0.090	1.160	2.760	2.890	3.030	13790
1000	1	0.090	1.310	3.080	3.280	3.440	18130

XLPE/PVC/AIA/PVC

AWG Size		Insulation Thickness (in.)	Approximate Diameter (Over)				Net Weight w/Armour
Cond.	Bond Wire	Insulation Thickness (in.)	Insul (in.)	Inner Jacket (in.)	Armour (in.)	Outer Jacket (in.)	kg/km
14	14	0.045	0.170	0.430	0.650	0.730	326
12	14	0.045	0.180	0.470	0.690	0.770	380
10	12	0.045	0.210	0.510	0.730	0.810	433
8	10	0.045	0.240	0.600	0.820	0.900	584
6	8	0.060	0.310	0.720	0.940	1.020	827
4	8	0.060	0.350	0.850	1.070	1.160	1107
3	6	0.060	0.380	0.930	1.150	1.230	1347
2	6	0.060	0.420	0.980	1.200	1.280	1533
1	6	0.080	0.490	1.120	1.340	1.420	1838
1/0	6	0.080	0.530	1.230	1.450	1.530	2120
2/0	6	0.080	0.580	1.280	1.500	1.580	2470
3/0	4	0.080	0.630	1.370	1.590	1.690	2969
4/0	4	0.080	0.690	1.480	1.700	1.790	3497
250	4	0.090	0.750	1.620	1.840	1.930	4135
300	4	0.090	0.760	1.765	2.005	2.115	4972
350	3	0.090	0.860	1.870	2.090	2.180	5431
400	3	0.090	0.850	1.945	2.185	2.295	6171
500	2	0.090	0.990	2.110	2.330	2.450	7284
750	2	0.090	1.160	2.450	2.670	2.790	10226
1000	1	0.090	1.310	2.760	2.980	3.100	13382

Four Conductor 1000V
XLPE/PVC/AIA/PVC

AWG Size		Insulation Thickness (in.)	Approximate Diameter (Over)				Net Weight w/Armour
Cond.	Bond Wire	Insulation Thickness (in.)	Insul (in.)	Inner Jacket (in.)	Armour (in.)	Outer Jacket (in.)	kg/km
14	14	0.045	0.170	0.500	0.720	0.800	430
12	14	0.045	0.180	0.570	0.790	0.880	531
10	12	0.045	0.210	0.630	0.850	0.930	677
8	10	0.045	0.240	0.700	0.920	1.000	816
6	8	0.060	0.310	0.930	1.150	1.250	1350
4	8	0.060	0.350	1.040	1.260	1.350	1738
3	6	0.060	0.380	1.090	1.310	1.400	2043
2	6	0.060	0.420	1.150	1.370	1.460	2356
1	6	0.080	0.490	1.380	1.600	1.720	3024
1/0	6	0.080	0.530	1.470	1.690	1.810	3520
2/0	6	0.080	0.580	1.570	1.790	1.910	4085
3/0	4	0.080	0.630	1.690	1.910	2.030	5057
4/0	4	0.080	0.690	1.870	2.090	2.210	6205
250	4	0.090	0.750	2.010	2.230	2.250	7126
350	3	0.090	0.860	2.240	2.460	2.600	9385
500	3	0.090	0.990	2.540	2.760	2.900	12556
750	2	0.090	1.160	3.020	3.240	3.420	18468
