XLPE Insulated Control Cable N2XY 0.6/1kV Copper Conductor: Technical Specification & Applications
.jpg)
What’s the N2XY Cable All About?
Why XLPE Insulation Rocks
The N2XY cable uses cross-linked polyethylene (XLPE) insulation, and that’s a big deal. This stuff has awesome electrical and physical strengths. It lets the cable carry more power in all kinds of situations. Plus, it keeps energy loss low with its high insulation resistance. That means better power delivery. Compared to older materials like PVC, XLPE of N2XY cable has higher operating temperatures and current-carrying capacities.The Power of Copper Conductors
Copper is a superstar in cables because it conducts electricity so well and lasts forever. The N2XY cable comes with copper conductors that can be solid or stranded, round or compressed, depending on what you need. Copper’s low resistance saves energy during transmission. It keeps things running smoothly for years. And because it’s flexible, it’s easier to install without breaking.Where Control Cables Fit In
Control cables like the N2XY are key for systems that need precise monitoring and control. They’re great for fixed setups in control circuits, monitoring gear, or protection systems up to 0.6/1 kV. You’ll see them in factories, power grids, and building systems because they’re so dependable and adaptable.Technical Breakdown of the N2XY Cable
How it’s produced.
Core Design Basics
The N2XY’s conductor is top-notch copper. You can get it in Class 1 (solid) , Class 2 (stranded) or Class 5. This lets you choose what works best for your project’s electrical or physical needs. The core is designed to perform steadily across tons of uses. It also follows global rules like IEC 60228.Outer Sheath Features
The cable’s outer layer is polyvinyl chloride (PVC). It’s tough and guards against environmental hazards. PVC holds up against oil and sunlight, ensuring long durability in harsh environments like underground or industrial zones.Electrical Specs
Voltage and Power Handling
The N2XY is rated for AC voltage at U0/U = 0.6/1 kV. It’s perfect for low-voltage systems where steady power is a must. The XLPE insulation makes it even better at carrying bigger loads without risking safety or efficiency.Current-carrying capacity
XLPE has a long-term operating temperature of 90°C, which is higher than that of PVC. It also features higher and more stable current-carrying capacities, enabling a wider range of applications.Physical Strengths
- Flexibility: Stranded copper conductors and PVC sheathing make the N2XY super bendy. It’s still tough, though. This makes it easy to install in tight or tricky spots.
- Tough Against the Elements: The PVC sheath fights off sunlight, and oil. So, the cable’s great for both indoor and outdoor jobs where conditions get rough.
Where the N2XY Cable Shines
Industrial Jobs
Powering Factories
The N2XY cable is a favorite in factories for distributing power. It handles low-voltage electricity like a champ. It’s good for underground use if you add some extra protection. Its tough design keeps things running in rough industrial settings. Steady power is crucial for keeping production going.The copper conductor—solid or stranded—delivers top conductivity and toughness. XLPE insulation helps it manage bigger power loads in different conditions. It cuts energy waste and keeps current carrying capacity high. That’s why it’s perfect for heavy machines and gear in factories.
Connecting Automation Systems
In today’s factories, automation needs spot-on control and monitoring. The N2XY cable nails it for linking up automation systems and machines. Its strong electrical and physical traits keep it reliable. The PVC sheath stands up to oil,and sunlight. That means it lasts even in tough industrial spots.The stranded copper conductor’s bendiness makes it easy to install in the tricky layouts you find in automation setups. Its heat resistance keeps it steady even when temperatures change. It’s a solid choice for industrial automation.
Commercial Uses
Running Building Systems
Building management systems (BMS) need good control cables to tie together things like lights, security, and HVAC. The N2XY cable is a great fit because it’s reliable and flexible. Its copper conductor and XLPE insulation give it strong electrical and physical qualities.It can handle up to 0.6/1 kV, so it’s ideal for powering and controlling BMS devices. It keeps working well over time, even in tough commercial spaces.
Big Infrastructure Projects
Transportation Networks
Big projects like transportation systems need durable control cables for heavy-duty tasks. The N2XY cable fits the bill with its strong design and global standards like IEC 60502-1. Its copper conductor keeps resistance low and power delivery steady.It’s awesome for underground setups with extra protection. It holds up against oil and sunlight, so it lasts in outdoor spots like railway signals or traffic control systems.
